Description
Product Specifications:
| Specification | Details |
|---|---|
| Paper thickness | Duplex box: 200–800 g/m²; N, F, E flute (corrugated); 3-ply E flute (3.5–4 mm thickness) |
| Max. speed | 300 m/min |
| Straight line box (A) | 180 – 1150 mm |
| Straight line box (B) | 85 – 800 mm |
| Lock bottom box (A) | 200 – 1100 mm |
| Lock bottom box (B) | 100 – 800 mm |
| Lock bottom box (C) | 60 – 700 mm |
| Lock bottom box (D) | 15 – 150 mm |
| Power | 14 kW |
| Power supply | AC 380V, 3 phase, 50 Hz |
| Machine size (L × W × H) | 14500 × 1450 × 1500 mm |
| Weight | 6500 kg |
