eFlex Printing Machine – High-Efficiency Flexo Press for Labels & Packaging
Elevate your printing operations in Bangladesh with the Focus EFLEX, the pinnacle of UK-engineered flexographic printing technology. Designed for unparalleled precision, efficiency, and versatility, the EFLEX is a fully servo-driven printing press that empowers your business to meet the demanding quality standards of both local and global markets.
- Model name: PT
- Payment Method: L/C at Sight or T/T in Advance
- Min. Order: 01
- Warranty: 12 Months
- Packaging: Standard Export Wooden Case
Share:
Request a quote for
Request a quote for
eFlex Printing Machine – High-Efficiency Flexo Press for Labels & Packaging
Elevate your printing operations in Bangladesh with the Focus EFLEX, the pinnacle of UK-engineered flexographic printing technology. Designed for unparalleled precision, efficiency, and versatility, the EFLEX is a fully servo-driven printing press that empowers your business to meet the demanding quality standards of both local and global markets.
- Model name: PT
- Payment Method: L/C at Sight or T/T in Advance
- Min. Order: 01
- Warranty: 12 Months
- Packaging: Standard Export Wooden Case
Share:
Product Info
EFLEX
From high-volume garment tags to premium food packaging and secure pharmaceutical cartons, the EFLEX platform minimizes waste, accelerates job changeovers, and maximizes profitability. Invest in the future of printing with a machine that adapts to your needs and grows with your business.Product Specification
| Web Width | 330mm-430mm |
| Number of Colours | 2 to 12 |
| Min Print Length | 7”(178mm) |
| Max Print Length | 20”(508mm) |
| Max Unwind | 1000mm |
| Pre-Register | Yes |
| Auto register | Yes |
| 2nd Pass | Option |
| Rail Mounted Equipment | Option |
| Drying Systems | IR,UV or LED |
| Chill Rolls | Option |
| Rotary Die Stations | Yes |
| Slitting | Yes |
| Max Rewind | 800mm |
| Rotary Die Sheet Station | Yes |
| Digital Ink jet Module | Option |
| Other Option | Turn bar, Delam/Relam, Lamination, Digital Ink Jet, Cold foil, Hot Foil, Rotary Silk Screen, Sheet Stacker, Corona Treater, Web Cleaner, Auto Register, Fan Folder, Ticket Streamer, U.V Drying, Chill Rolls. |
Advantage & Features
- MAXIMISE PRESS TIME: The eFlex increases efficiency by allowing off-press cleaning of ink cartridges and Anilox rolls, reducing setup, job changes, downtime, and waste, leading to higher profits and quicker ROI.
- ENERGY MANAGEMENT: Servo drives and digital ink drying systems reduce energy costs by directing power only where needed, lowering overall consumption.
- SERVO TECHNOLOGY: Independent servo drives at each print and die station ensure precise control and avoid tension issues on substrates.
- HMI: The touchscreen interface streamlines setup and stores job data for future runs.
- PRE-REGISTER & IMPRESSION SETTING: Automatic register adjustments and micro-tuning optimize print quality without material waste, regardless of substrate thickness.
- AUTO REGISTER: Achieves accurate register without operator intervention, even on unsupported substrates, minimizing waste through touch screen-controlled adjustments.
- QC JOB & COLOUR CHANGES: Open print head design enables quick, waste-free job and colour changes. Ink cartridges are easily swapped and cleaned off-line.
- SUBSTRATES: Handles a wide range of substrates, from 30 to 380 Micron, including unsupported films, standard labels, and carton board.
- CONVERTING OPTIONS: Rail-mounted systems offer flexible positioning of ancillary platforms for customizable setups.
Applications
The versatility of the EFLEX makes it the ideal production asset for a wide array of high-value products in the Bangladesh market:
- Labels: Self-adhesive labels, wrap-around labels, shrink sleeves, and in-mould labels.
- Garment Accessories: High-volume hang tags, price tags, and care labels on various materials.
- Flexible Packaging: Pouches, sachets, and wrappers for the food and consumer goods industries.
- Folding Cartons: A highly capable carton printing machine for the pharmaceutical, cosmetics, and food sectors.
- Security Printing: Tamper-evident labels, security tapes, and tickets requiring precise registration.
- Specialty Films: Printing on a variety of filmic substrates for industrial and commercial use.
Specification
EFLEX
From high-volume garment tags to premium food packaging and secure pharmaceutical cartons, the EFLEX platform minimizes waste, accelerates job changeovers, and maximizes profitability. Invest in the future of printing with a machine that adapts to your needs and grows with your business.Product Specification
| Web Width | 330mm-430mm |
| Number of Colours | 2 to 12 |
| Min Print Length | 7”(178mm) |
| Max Print Length | 20”(508mm) |
| Max Unwind | 1000mm |
| Pre-Register | Yes |
| Auto register | Yes |
| 2nd Pass | Option |
| Rail Mounted Equipment | Option |
| Drying Systems | IR,UV or LED |
| Chill Rolls | Option |
| Rotary Die Stations | Yes |
| Slitting | Yes |
| Max Rewind | 800mm |
| Rotary Die Sheet Station | Yes |
| Digital Ink jet Module | Option |
| Other Option | Turn bar, Delam/Relam, Lamination, Digital Ink Jet, Cold foil, Hot Foil, Rotary Silk Screen, Sheet Stacker, Corona Treater, Web Cleaner, Auto Register, Fan Folder, Ticket Streamer, U.V Drying, Chill Rolls. |
Advantage & Features
Advantage & Features
- MAXIMISE PRESS TIME: The eFlex increases efficiency by allowing off-press cleaning of ink cartridges and Anilox rolls, reducing setup, job changes, downtime, and waste, leading to higher profits and quicker ROI.
- ENERGY MANAGEMENT: Servo drives and digital ink drying systems reduce energy costs by directing power only where needed, lowering overall consumption.
- SERVO TECHNOLOGY: Independent servo drives at each print and die station ensure precise control and avoid tension issues on substrates.
- HMI: The touchscreen interface streamlines setup and stores job data for future runs.
- PRE-REGISTER & IMPRESSION SETTING: Automatic register adjustments and micro-tuning optimize print quality without material waste, regardless of substrate thickness.
- AUTO REGISTER: Achieves accurate register without operator intervention, even on unsupported substrates, minimizing waste through touch screen-controlled adjustments.
- QC JOB & COLOUR CHANGES: Open print head design enables quick, waste-free job and colour changes. Ink cartridges are easily swapped and cleaned off-line.
- SUBSTRATES: Handles a wide range of substrates, from 30 to 380 Micron, including unsupported films, standard labels, and carton board.
- CONVERTING OPTIONS: Rail-mounted systems offer flexible positioning of ancillary platforms for customizable setups.
Applications
Applications
The versatility of the EFLEX makes it the ideal production asset for a wide array of high-value products in the Bangladesh market:
- Labels: Self-adhesive labels, wrap-around labels, shrink sleeves, and in-mould labels.
- Garment Accessories: High-volume hang tags, price tags, and care labels on various materials.
- Flexible Packaging: Pouches, sachets, and wrappers for the food and consumer goods industries.
- Folding Cartons: A highly capable carton printing machine for the pharmaceutical, cosmetics, and food sectors.
- Security Printing: Tamper-evident labels, security tapes, and tickets requiring precise registration.
- Specialty Films: Printing on a variety of filmic substrates for industrial and commercial use.
Product Comparison
Product Comparison Table with Similar Products
| Feature | Focus EFLEX | Nilpeter FA-Line | Mark Andy P7E | Generic Regional Models |
| Drive Technology | Twin Servo per Print Head | Full Servo | Full Servo | Varies (Geared or Basic Servo) |
| Automation Level | High (Auto-Register, Job Save) | High (Auto-Lock, Mobile Controls) | High (Mark Andy AI, Auto-Setup) | Low to Moderate |
| Waste Reduction | Excellent (Short Web Path, Pre-Register) | Excellent | Excellent | Moderate to High |
| Versatility | High (Labels, Films, Cartons) | High (Labels, Films, Sleeves) | High (Labels, Films, Flex-Pack) | Often specialized (e.g., fabric labels only) |
| Local Support (BD) | Excellent (Dedicated Agent: Prominent Tec) | Strong (Regional Hub in India) | Strong (Regional Agent in India) | Variable / Limited |
| Ideal For | Quality-focused converters needing versatility & local support. | High-end converters with strong regional ties. | High-volume converters needing advanced automation. | Price-sensitive, low-spec domestic production. |
Product Warranty
Warranty Period: 12 Months.
Warranty Terms: The EFLEX comes with a service warranty that covers key mechanical and electronic components such as servo motors, drive modules, and the central control interface. Some items—like nip rollers, ink trays, UV bulbs, and other regularly replaced parts—naturally wear out over time and are considered consumables, so they aren’t covered under the warranty. If any covered part stops working during the warranty period, our technicians will handle the repair or replacement, but customers will need to purchase any necessary spare parts. Please note that customers are responsible for all shipping costs when sending or receiving parts or equipment.
Technical & After Sales Service
To help you get the best results, we provide robust after-sales support, including:
- On-site installation, setup, and training to ensure smooth integration into your workflow.
- Field servicing and repair visits upon request for issues that require hands-on attention.
- Dedicated customer service channels, including 24/7 phone support for quick resolution of queries or concerns.
- Regional technical assistance (where available) to reduce machine downtime and maintain productivity.
Delivery Time
30-45 days. Please contact our sales team for precise delivery estimates for machine purchases.
Product Warranty
Product Warranty
Warranty Period: 12 Months.
Warranty Terms: The EFLEX comes with a service warranty that covers key mechanical and electronic components such as servo motors, drive modules, and the central control interface. Some items—like nip rollers, ink trays, UV bulbs, and other regularly replaced parts—naturally wear out over time and are considered consumables, so they aren’t covered under the warranty. If any covered part stops working during the warranty period, our technicians will handle the repair or replacement, but customers will need to purchase any necessary spare parts. Please note that customers are responsible for all shipping costs when sending or receiving parts or equipment.
Technical & After Sales Service
Technical & After Sales Service
To help you get the best results, we provide robust after-sales support, including:
- On-site installation, setup, and training to ensure smooth integration into your workflow.
- Field servicing and repair visits upon request for issues that require hands-on attention.
- Dedicated customer service channels, including 24/7 phone support for quick resolution of queries or concerns.
- Regional technical assistance (where available) to reduce machine downtime and maintain productivity.
Delivery Time
Delivery Time
30-45 days. Please contact our sales team for precise delivery estimates for machine purchases.
Company Info
Prominent Tec Company Information
Address: House #9, Block #A, Road #1, Niketon, Dhaka-1212, Bangladesh.
Business Type: Importer, Indenting & Distributor, Agents
Business Range: Printing Machinery & Consumables
Main Products: Textile Label Printing Machine, Garments Printing Machine, Digital Garments Printing Machine, Paper & Packaging Printing Machine, Printing Inks, Chemicals, Mesh, Squeegee, Ribbon, Flexo Photopolymer Plates, CTP Plate
About us: Established in 2010, Prominent Tec is a leading importer, indenting agent, and distributor specializing in advanced printing machinery and high-quality consumables. We represent renowned international brands such as Focus Label Machinery (UK), Ink Tec Inc. (USA), and Azon Printer (Croatia), among others, providing comprehensive printing solutions tailored to the garment, textile, packaging, plastic, and metal printing industries. With a dedicated team of professionals, robust warehouse facilities, and a commitment to exceptional service, Prominent Tec ensures reliable supply and technical support, helping our customers achieve efficiency and excellence in their printing operations.
Delivery Time 30-45 days. Please contact our sales team for precise delivery estimates for machine purchases.
A1. European-built with local support from Prominent Tec, EFLEX is ideal for RMG, food, and pharma packaging.
Q2. Can the EFLEX handle sustainable and recycled materials?
A2. Yes, it runs recycled and eco-films efficiently with low waste, meeting green standards.
Q3. How does the EFLEX servo technology help reduce operational costs?
A3. It cuts waste, shortens changeovers, and lowers energy use.
Q4. Is this EFLEX the same as an EFLEX wire bending machine?
A4. No, this EFLEX is a Focus flexo press, not related to wire bending machines.
Q5. What kind of finishing options can be added to the EFLEX?
A5. It supports die-cutting, sheeting, lamination, cold foil, turn bars, and embellishment units.
