Platemaking Systems Machine for Precision Flexographic Plate Production
Revolutionize your printing operations in Bangladesh with an in-house Platemaking Systems Machine. Gain complete control over your production schedule, dramatically reduce turnaround times, and achieve superior print quality for labels and packaging.
- Model name: PT
- Payment Method: L/C at Sight or T/T in Advance
- Min. Order: 01
- Warranty: 12 Months
- Packaging: Standard Export Wooden Case
Share:
Request a quote for
Request a quote for
Platemaking Systems Machine for Precision Flexographic Plate Production
Revolutionize your printing operations in Bangladesh with an in-house Platemaking Systems Machine. Gain complete control over your production schedule, dramatically reduce turnaround times, and achieve superior print quality for labels and packaging.
- Model name: PT
- Payment Method: L/C at Sight or T/T in Advance
- Min. Order: 01
- Warranty: 12 Months
- Packaging: Standard Export Wooden Case
Share:
Product Info
Platemaking Systems Machine
This all-in-one Flexo Photopolymer Plate Making Machine is your key to unlocking higher efficiency, reducing operational costs, and securing a competitive edge in the fast-paced world of Flexo Graphics. Stop relying on external suppliers and start producing high-resolution, durable flexo plates on your own terms.Product SpecificationÂ
| A3/S Profile | A2/S Profile | A1/S Profile | |
| Max plate size mm | 370×520 | 530×760 | 700×900 |
| UVA exp. lamps | 9x40W 10R L. 590 | 14x40W 10R L. 590 | 14x60W 10R L. 1200 |
| Uvc lamps | 10x15W L. 437 | 12x30W L. 894 | 11x36W L. 1200 |
| Stainless steel tank lt. | 27 | 50 | 110 |
| Heater | 600W | 2x600W | 3x600W |
| Electrical | 230/400V 50/60HZ | 230/400V 50/60HZ | 230/400V 50/60HZ |
| Overall size (LxWxH) cm | 77x101x120 | 106x108x120 | 45x126x120 |
| Weight kg. | 174 | 260 | 380 |
Advantage & FeaturesÂ
- The 9-channel controller manages all steps at once: pre-exposure time, UVC exposure, processing temperature, exposure duration, processing time, dryer temperature, post-exposure time, and drying time.
- Channels include: one for pre-exposure, one with pump for exposure, one for post-exposure with UVC lamps, two for washout, and one for the drying function.
- The exposure section includes an exhaust system and multiple lamps, ensuring even exposure across different plate sizes.
- Plates are processed in a stainless steel tank using an orbital motion plate-holder table (tiltable in model A1) and adjustable-height brushes.
- The post-exposure area, also stainless steel, features an independent suction system separate from the washout tank and dryer.
ApplicationsÂ
The versatility of the Flexo Photopolymer Plate Making Machine makes it essential for various key sectors in Bangladesh:
- Garment & Apparel Industry: Perfect for producing high-quality fabric care labels, brand tags, and printed ribbons.
- Flexible Packaging: Ideal for printing on films and laminates for snacks, spices, detergents, and other consumer goods.
- Label Printing: Essential for creating self-adhesive labels for food products, pharmaceuticals, cosmetics, and industrial goods.
- Paper & Board Packaging: Capable of producing plates for printing on corrugated boxes, cartons, and paper bags.
Specification
Platemaking Systems Machine
This all-in-one Flexo Photopolymer Plate Making Machine is your key to unlocking higher efficiency, reducing operational costs, and securing a competitive edge in the fast-paced world of Flexo Graphics. Stop relying on external suppliers and start producing high-resolution, durable flexo plates on your own terms.Product SpecificationÂ
| A3/S Profile | A2/S Profile | A1/S Profile | |
| Max plate size mm | 370×520 | 530×760 | 700×900 |
| UVA exp. lamps | 9x40W 10R L. 590 | 14x40W 10R L. 590 | 14x60W 10R L. 1200 |
| Uvc lamps | 10x15W L. 437 | 12x30W L. 894 | 11x36W L. 1200 |
| Stainless steel tank lt. | 27 | 50 | 110 |
| Heater | 600W | 2x600W | 3x600W |
| Electrical | 230/400V 50/60HZ | 230/400V 50/60HZ | 230/400V 50/60HZ |
| Overall size (LxWxH) cm | 77x101x120 | 106x108x120 | 45x126x120 |
| Weight kg. | 174 | 260 | 380 |
Advantage & Features
Advantage & FeaturesÂ
- The 9-channel controller manages all steps at once: pre-exposure time, UVC exposure, processing temperature, exposure duration, processing time, dryer temperature, post-exposure time, and drying time.
- Channels include: one for pre-exposure, one with pump for exposure, one for post-exposure with UVC lamps, two for washout, and one for the drying function.
- The exposure section includes an exhaust system and multiple lamps, ensuring even exposure across different plate sizes.
- Plates are processed in a stainless steel tank using an orbital motion plate-holder table (tiltable in model A1) and adjustable-height brushes.
- The post-exposure area, also stainless steel, features an independent suction system separate from the washout tank and dryer.
Applications
ApplicationsÂ
The versatility of the Flexo Photopolymer Plate Making Machine makes it essential for various key sectors in Bangladesh:
- Garment & Apparel Industry: Perfect for producing high-quality fabric care labels, brand tags, and printed ribbons.
- Flexible Packaging: Ideal for printing on films and laminates for snacks, spices, detergents, and other consumer goods.
- Label Printing: Essential for creating self-adhesive labels for food products, pharmaceuticals, cosmetics, and industrial goods.
- Paper & Board Packaging: Capable of producing plates for printing on corrugated boxes, cartons, and paper bags.
Product Comparison
Product Comparison Table with Similar Products
| Feature | Entry-Level (A4/A3) | Mid-Range (A2/A1) | Advanced Digital CTP |
| Primary Use | Narrow web labels, small jobs | General packaging, labels | High-volume, premium packaging |
| Max Plate Size | Approx. 300 x 420 mm | Approx. 635 x 762 mm | Approx. 900 x 1200 mm |
| Technology | Analogue (requires film) | Analogue / Digital Ready | Digital (Computer-to-Plate) |
| Wash System | Solvent / Water Wash | Solvent / Water Wash | Solvent / Water / Thermal |
| Speed | Standard | Fast | Very Fast (Automated) |
| Resolution | Good | Excellent | Superior (HD Flexo) |
| Best For | Startups, low-volume printers | Established printers, diverse jobs | Large converters, export-focused |
Product WarrantyÂ
Warranty Period: 12 Months.Â
Warranty Terms: The Flexo Graphics (Platemaking Systems Machine) comes with a service warranty that covers core operational parts including the UV exposure unit, vacuum frame system, and electronic control modules. Some items—like brushes, filters, UV tubes, and other routine maintenance components—naturally wear out over time and are considered consumables, so they aren’t covered under the warranty. If any covered part stops working during the warranty period, our technicians will handle the repair or replacement, but customers will need to purchase any necessary spare parts. Please note that customers are responsible for all shipping costs when sending or receiving parts or equipment.
Technical & After Sales Service
To help you get the best results, we provide robust after-sales support, including:
- On-site installation, setup, and training to ensure smooth integration into your workflow.
- Field servicing and repair visits upon request for issues that require hands-on attention.
- Dedicated customer service channels, including 24/7 phone support for quick resolution of queries or concerns.
- Regional technical assistance (where available) to reduce machine downtime and maintain productivity.
Delivery TimeÂ
30-45 days. Please contact our sales team for precise delivery estimates for machine purchases.
Product Warranty
Product WarrantyÂ
Warranty Period: 12 Months.Â
Warranty Terms: The Flexo Graphics (Platemaking Systems Machine) comes with a service warranty that covers core operational parts including the UV exposure unit, vacuum frame system, and electronic control modules. Some items—like brushes, filters, UV tubes, and other routine maintenance components—naturally wear out over time and are considered consumables, so they aren’t covered under the warranty. If any covered part stops working during the warranty period, our technicians will handle the repair or replacement, but customers will need to purchase any necessary spare parts. Please note that customers are responsible for all shipping costs when sending or receiving parts or equipment.
Technical & After Sales Service
Technical & After Sales Service
To help you get the best results, we provide robust after-sales support, including:
- On-site installation, setup, and training to ensure smooth integration into your workflow.
- Field servicing and repair visits upon request for issues that require hands-on attention.
- Dedicated customer service channels, including 24/7 phone support for quick resolution of queries or concerns.
- Regional technical assistance (where available) to reduce machine downtime and maintain productivity.
Delivery Time
Delivery TimeÂ
30-45 days. Please contact our sales team for precise delivery estimates for machine purchases.
Company Info
Prominent Tec Company Information
Address: House #9, Block #A, Road #1, Niketon, Dhaka-1212, Bangladesh.
Business Type: Importer, Indenting & Distributor, Agents
Business Range: Printing Machinery & Consumables
Main Products: Textile Label Printing Machine, Garments Printing Machine, Digital Garments Printing Machine, Paper & Packaging Printing Machine, Printing Inks, Chemicals, Mesh, Squeegee, Ribbon, Flexo Photopolymer Plates, CTP Plate
About us: Established in 2010, Prominent Tec is a leading importer, indenting agent, and distributor specializing in advanced printing machinery and high-quality consumables. We represent renowned international brands such as Focus Label Machinery (UK), Ink Tec Inc. (USA), and Azon Printer (Croatia), among others, providing comprehensive printing solutions tailored to the garment, textile, packaging, plastic, and metal printing industries. With a dedicated team of professionals, robust warehouse facilities, and a commitment to exceptional service, Prominent Tec ensures reliable supply and technical support, helping our customers achieve efficiency and excellence in their printing operations.
Q1. What exactly is a Flexo Graphics (Platemaking Systems Machine) and why do I need one?
A1. It’s an in-house photopolymer plate maker that ensures control, speed, cost savings, and quality for Bangladeshi printers..
Q2. How much does a Platemaking Systems Machine cost in Bangladesh?
A2. Costs depend on size, automation, and features. Entry models are cheaper; wide-web units cost more. Contact us for a quote.
Q3. Do I need to hire a specialized operator to run a Flexo Photopolymer Plate Making Machine?
A3. No. It’s user-friendly, and staff can be trained in a day with full installation support.
Q4. How long does it take to make a complete set of plates with this machine?
A4. Press-ready plates in under 60 minutes—perfect for urgent jobs and quick delivery.
Q5. Can this machine produce high-resolution, digital "HD Flexo" plates?
A5. Yes, with a CTP imager. Our machines are digital-ready and support HD Flexo imaging.
